Maximum Operating Depth (MOD): what it is and how to use it safely
MOD tells you the maximum depth for a given gas mix before oxygen exposure becomes unsafe. This guide explains the concept in simple terms, with clear examples.
- MOD defines the maximum safe depth for a gas mix.
- It depends on oxygen percentage and chosen ppO₂ limit.
- Used correctly, it helps prevent oxygen toxicity.
- What is MOD?
- Why MOD matters
- MOD formula explained
- Practical examples
- Nitrox MOD table
- Common mistakes
- Quick checklist
- Gas mix: EAN32
- ppO₂ limit: 1.4
- Resulting MOD: approximately 33–34 meters
- Example 1: EAN36 is suitable for shallower dives due to higher oxygen content.
- Example 2: Air allows deeper MOD but offers less decompression benefit.
- Example 3: Technical mixes require strict labeling and verification.
- Using the wrong ppO₂ value during planning.
- Assuming MOD is the same for all dives.
- Failing to label or verify gas mixes.
- ✅ Confirm gas mix
- ✅ Choose appropriate ppO₂ limit
- ✅ Calculate MOD
- ✅ Set dive computer accordingly
- ✅ Stay within planned depth
What is MOD?
Maximum Operating Depth (MOD) is the deepest depth at which a specific breathing gas can be safely used without exceeding a chosen oxygen partial pressure (ppO₂).
Why MOD matters
Exceeding MOD increases the risk of oxygen toxicity, which can have serious and immediate consequences underwater. MOD is a core concept in dive planning for both recreational and technical diving.
MOD formula explained
MOD is calculated using the oxygen fraction of the gas and a selected ppO₂ limit. Divers choose conservative limits based on training and dive conditions.
Metric (metres): MOD = 10 × (ppO₂ ÷ FO₂ − 1)
Imperial (feet): MOD = 33 × (ppO₂ ÷ FO₂ − 1)
ppO₂ = your chosen oxygen partial-pressure limit (1.4 bar working, 1.6 bar contingency); FO₂ = the oxygen fraction of the mix (for example 0.32 for EAN32).
Worked example − EAN32 at ppO₂ 1.4: 1.4 ÷ 0.32 = 4.375; − 1 = 3.375; × 10 = 33 m (rounded down, matching the table below).
Practical examples
Nitrox Maximum Depth Chart — MOD by mix (ppO₂ 1.4 / 1.6)
Ready-to-use nitrox depth limits — the maximum safe depth (MOD) for each EANx mix. For example, the maximum depth for 32% nitrox (EAN32) is 33 m at ppO₂ 1.4 and 40 m at 1.6. Depths are metres of seawater, rounded down to stay conservative.
| Gas mix | MOD @ ppO₂ 1.4 | MOD @ ppO₂ 1.6 |
|---|---|---|
| Air (21% O₂) | 56 m | 66 m |
| EAN28 | 40 m | 47 m |
| EAN30 | 36 m | 43 m |
| EAN32 | 33 m | 40 m |
| EAN34 | 31 m | 37 m |
| EAN36 | 28 m | 34 m |
| EAN38 | 26 m | 32 m |
| EAN40 | 25 m | 30 m |
| EAN50 | 18 m | 22 m |
| EAN80 | 7 m | 10 m |
| Oxygen (100% O₂) | 4 m | 6 m |
Common mistakes
Quick checklist
FAQ
Is MOD the same for every diver?
No. MOD depends on training standards, chosen safety margins, and dive objectives.
Can I exceed MOD briefly?
No. MOD should be treated as an absolute limit, not a guideline.
Does my dive computer calculate MOD automatically?
Most modern dive computers do, but the diver is still responsible for planning and verification.
What is the MOD of 32% nitrox?
The MOD of EAN32 (32% oxygen) is 33 m (108 ft) at the standard ppO₂ limit of 1.4, or 40 m (131 ft) at the contingency limit of 1.6. See the full nitrox MOD table above.
What is the MOD for 36% nitrox?
The MOD of EAN36 (36% oxygen) is 28 m (92 ft) at ppO₂ 1.4, or 34 m (112 ft) at ppO₂ 1.6.
How do you calculate MOD for nitrox?
MOD = 10 × (ppO₂ ÷ FO₂ − 1), in metres of seawater. Divide your chosen ppO₂ limit by the oxygen fraction of your gas mix, subtract 1, then multiply by 10. See the MOD formula explained section for worked examples.
